162,880 Parts Listed!!

[NEW] JDM TOYOTA COROLLA Cross ZSG10 Front Bumper

[NEW] JDM TOYOTA COROLLA Cross ZSG10 Front Bumper...

$19.45 USD
$19.45 USD
Sold out
Shipping calculated at checkout.

Fitting Model :

TOYOTA COROLLA Cross ZSG10

Note :

Front Bumper

Parts Information :

Front Bumper

No
Parts Number
Parts Name
1
 52119-16590-A0 Front Bumper Cover X Body Color Code (089)
1
 52119-16590-B0 Front Bumper Cover X Body Color Code (1H5)
1
 52119-16590-B1 Front Bumper Cover X Body Color Code (1L0)
1
 52119-16590-C2 Front Bumper Cover X Body Color Code (218)
1
 52119-16590-C1 Front Bumper Cover X Body Color Code (220)
1
 52119-16590-D0 Front Bumper Cover X Body Color Code (3T3)
1
 52119-16590-E0 Front Bumper Cover X Body Color Code (4V8)
1
 52119-16590-J0 Front Bumper Cover X Body Color Code (8W7)
1
 52119-16929-A0 Front Bumper Cover Standard Spec Body Color Code (089)
1
 52119-16929-C1 Front Bumper Cover Standard Spec Body Color Code (218)
1
 52119-16929-C0 Front Bumper Cover Standard Spec Body Color Code (220)
1
 52119-16929-B0 Front Bumper Cover Standard Spec Body Color Code (1H5)
1
 52119-16929-B1 Front Bumper Cover Standard Spec Body Color Code (1L0)
1
 52119-16929-D0 Front Bumper Cover Standard Spec Body Color Code (2TT)
1
 52119-16929-E0 Front Bumper Cover Standard Spec Body Color Code (4V8)
1
 52119-16929-J0 Front Bumper Cover Standard Spec Body Color Code (8W7)
2
 89348-48311 Ultrasonic Sensor Retainer Front Corner
3
 90167-50063 Screw No.1
4
 90467-07215 Front Bumper Clip No.1
5
 75392-35220 Front Bumper Retainer
6
 52129-16900 Front Bumper Cover Lower
7
 90179-06127 Nut
8
 90183-05040 Nut
9
 53128-16010 Front Bumper Hole Cover
10
 51960-16030 Tow Hook Front Assy
11
 53116-16020 Radiator Grille Bracket No.2 with Panoramic View Monitor
11
 53116-16010 Radiator Grille Bracket No.2 without Panoramic View Monitor
12
 89437-16010 Front Bumper Hole Cover
13
 90167-50063 Screw No.1
14
 90189-06237 Screw Grommet
15
 75392-35220 Front Bumper Retainer
16
 52711-16040 Front Bumper Moulding
17
 53121-16060 Radiator Grille Moulding No.1 G
17
 53121-16070 Radiator Grille Moulding No.1 S
18
 81481-16030 Fog Lamp Cover (R) with Front Fog Lamp
18
 81481-16020 Fog Lamp Cover (R) without Front Fog Lamp (Front Bumper Hole Cover)
18
 81482-16030 Fog Lamp Cover (L) with Front Fog Lamp
18
 81482-16020 Fog Lamp Cover (L) without Front Fog Lamp (Front Bumper Hole Cover)
19
 53395-16020 Hood to Front End Panel Seal
20
 53145-60030 Clip
21
 53114-16050 Radiator Grille Upper
22
 52527-12060 Front Bumper Retainer Lower No.2
23
 90159-60621 Screw
24
 90189-06237 Screw Grommet
25
 90109-06388 Bolt
26
 90167-50063 Screw
27
 90467-05063-C0 Clip
28
 51420-16010 Engine Under Cover No.2 Assy
29
 90189-06193 Screw Grommet TYPE-A
29
 90189-06237 Screw Grommet TYPE-B
30
 90159-60477 Screw No.1
31
 90467-07220 Clip
32
 52535-16050 Front Bumper Side Retainer (R)
32
 52536-16040 Front Bumper Side Retainer (L)
33
 90467-09237 Front Bumper Side Retainer Clip (R)
34
 52611-16060 Front Bumper Energy Absorber
35
 52131-16110 Front Bumper Reinforcement
36
 91674-A1028 Bolt
37
 57013-16010 Front Side Member Bracket Sub Assy (R)
37
 57014-16010 Front Side Member Bracket Sub Assy (L)
38
 91674-A1028 Bolt (R)

Note :

This is JDM (Japanese Domestic Market) parts, So please make sure the item is fit with your car before purchase.

Shipping :

I will ship to world wide by expedited shipping carrier as EMS, DHL or Fedex! (include tracking number)
** You can check the total shipping fee before payment. Please go "ADD TO CART" and put the shipping information.
** Usually, we will ship items within 5 business days. But if it is stocked out in maker, the delivery will be delay. In that case, I will inform you.
